PowerPlex® Fusion System
Co-Amplification and Fluorescent Detection of 24 Loci
- Meets CODIS and European standards
- High inhibitor tolerance and sensitivity for casework
- One kit for both casework and database sections
Catalog Number:
Size
Catalog Number: DC2402
Catalog Number: DC2408
More Information and Superior Performance from a Single Kit
The PowerPlex® Fusion System provides all of the materials needed for co-amplification and fluorescent detection of 24 loci (23 STR loci and Amelogenin, but without SE33), including the CODIS core loci and European Standard Set (ESS) loci. This comprehensive set supports compatibility with present databases across multiple regions and encompasses an expanded set of loci to address future growth. The PowerPlex® Fusion System delivers more information and high success rates from demanding forensic, paternity and relationship-testing cases. Using proven STR chemistries for existing instrument platforms and software, this 5-color system requires no software or instrument upgrades.
Promega forensic products are manufactured in alignment with the ISO 18385 standard. This standard ensures minimal risk of human DNA contamination for products used to collect, store and analyze biological materials for forensic purposes. Learn more.
High Discriminatory Power
PowerPlex® Fusion loci set is exceptional. By combining US CODIS and ESS loci, the system offers significant gains in discriminatory power and helps ensure fewer adventitious matches are obtained.
A probability of identity value (PI) is defined as the probability that two individuals selected at random will have an identical genotype at the tested locus.
| STR Kit | Number of Loci | PI* (N = 1036) |
|---|---|---|
| GlobalFiler™ STR Kit | 23 | 1.63 × 10–27 |
| Investigator® 24plex Kit | 23 | 1.63 × 10–27 |
| PowerPlex® Fusion System | 24 | 1.38 × 10–28 |
| PowerPlex® Fusion 6C System | 27 | 9.09× 10–31 |
*Note: PI values do not include Amelogenin or Y-STRs.
Reference: Steffen, C.R. et al. (2017) FSI Genetics Corrigendum to ‘U.S. Population Data for 29 Autosomal STR Loci’. doi: https://doi.org/10.1016/j.fsigen.2017.08.011
Maximum Sensitivity
The PowerPlex® Fusion System reliably produces complete STR profiles from as little as 100pg of human DNA
Superior Inhibitor Tolerance
With a robust buffer system designed to tolerate the most challenging inhibitors, the PowerPlex® Fusion System minimizes the need to re-amplify samples generally thought to be too challenging to run, saving your lab countless hours of repeat analyses.
Direct-Amplification Compatibility for Most Sample Types
Building on the proven flexibility of our PowerPlex® 21 System, the PowerPlex® Fusion System allows direct amplification from FTA® card punches as well as pretreated nonFTA cards and commonly used swabs to streamline workflow and expand sample throughput.
Buccal Punch Card
Swab
FTA® Card Punch with Blood
Buccal Punch Card
Rapid Processing Solutions for PowerPlex® Systems
The 5X AmpSolution™ Reagent, SwabSolution™ Kit and PunchSolution™ Kit allow fast and simple processing of swabs and punches for analysis with various PowerPlex® Systems, including the PowerPlex® Fusion, 21, 18D, 16 HS, ESX, ESI, CS7 and Y23 Systems. These products are intended for preparation of single-source reference, database and paternity samples where sample purification is unnecessary.
Which Product is Right for Me?
Take me to the Product SelectorProtocols
Complete Protocol
Protocolos Rápidos
Specifications
Catalog Number:
Contenido
| Item | Part # | Presentación | Concentración | Available Separately |
|---|---|---|---|---|
|
2800M Control DNA |
DD710A | 1 × 25μl | 10ng/μl | View Product |
WEN Internal Lane Standard 500 |
DG500A | 1 × 200μl | View Product | |
| PowerPlex® Fusion Allelic Ladder Mix | DG381B | 1 × 100μl | ||
PowerPlex® Fusion 5X Primer Pair Mix |
DK236B | 1 × 1ml | ||
| PowerPlex® Fusion 5X Master Mix | DP207A | 1 × 1ml | ||
|
Water, Amplification Grade |
DW099A | 5 × 1,250μl | View Product |
SDS
Search for SDSCertificado de Análisis
Use Restrictions
Not For Medical Diagnostic Use.Condiciones de Almacenaje
U.S. Pat. No. 9,139,868, European Pat. No. 2972229, Japanese Pat. No. 6367307 and other patents pending.
TMR-ET, CXR-ET and WEN dyes are proprietary.
Contenido
| Item | Part # | Presentación | Concentración | Available Separately |
|---|---|---|---|---|
|
2800M Control DNA |
DD710A | 1 × 25μl | 10ng/μl | View Product |
WEN Internal Lane Standard 500 |
DG500A | 4 × 200μl | View Product | |
| PowerPlex® Fusion Allelic Ladder Mix | DG381B | 4 × 100μl | ||
PowerPlex® Fusion 5X Primer Pair Mix |
DK236B | 4 × 1ml | ||
| PowerPlex® Fusion 5X Master Mix | DP207A | 4 × 1ml | ||
|
Water, Amplification Grade |
DW099A | 10 × 1,250μl | View Product |
SDS
Search for SDSCertificado de Análisis
Use Restrictions
Not For Medical Diagnostic Use.Condiciones de Almacenaje
U.S. Pat. No. 9,139,868, European Pat. No. 2972229, Japanese Pat. No. 6367307 and other patents pending.
TMR-ET, CXR-ET and WEN dyes are proprietary.
